Caracteristici
Noise level	45 dB
Output power capacity	5 kVA
Input frequency	50/60 Hz
Output power	4500 W
Input operation voltage (max)	276 V
Input operation voltage (min)	176 V
Output operation voltage (max)	240 V
Output operation voltage (min)	200 V
Efficiency	98 %
Output voltage Total Harmonic Distortion (THD)	2 %
Input current Total Harmonic Distortion (THD)	5 %
Crest factor	3:1

Conexiune

AC outlets quantity 10 AC outlet(s) AC outlet types C13 coupler,C19 coupler RS-232 ports 1 USB 2.0 ports quantity 1

Design

Product colour Black Form factor Rackmount/Tower Certification IEC/EN 62040 -2, FCC Class A, IEC/EN 62040-3 CE, CB (TUV), UL Display type LCD Safety IEC/EN 62040-1, UL 1778, CSA 22.2

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C

Greutate şi dimensiuni

Weight 48000 g Width 130 mm Depth 685 mm Height 440 mm

Date logistice

Harmonized System (HS) code 85078000

Alte caracteristici

Output connections 8 x IEC-320-C13 & 2 x IEC-320-C19 Nominal input voltage 200-240 V Nominal output voltage 200-240 V
