Caracteristicile managementului
Switch type	Unmanaged

Conexiune

Gigabit Ethernet (copper) ports quantity 1 Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100) Basic switching RJ-45 Ethernet ports quantity 8

Reţea

Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x Auto MDI/MDI-X Yes 10G support No

Transmisie de date

Packet forwarding rate (100 Mbps) 148800 pps Packet forwarding rate (10 Mbps) 14880 pps MAC address table 2000 entries Switching capacity 1.8 Gbit/s Forwarding rate 2.67 Mpps Packet buffer memory 0.128 MB Store-and-forward Yes

Design

Product colour Black Rack mounting No LED indicators Activity,Link,PoE,Power,Speed Certification CE, RoHS

Performanță

Mean time between failures (MTBF) 52308 h

Managementul energiei

Power consumption (max) 102 W Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 8 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 92 W Power over Ethernet (PoE) power per port 30 W

Conditii de mediu

Heat dissipation 486.7 BTU/h Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -10 - 70 °C Storage relative humidity (H-H) 0 - 95 %

Greutate şi dimensiuni

Width 177 mm Depth 104 mm Height 26 mm Weight 410 g

Datele de ambalare

User guide Yes

Date logistice

Harmonized System (HS) code 85176990
