| General |
| Processor model | Intel® Core™ i5-1334U Prozessor (12 MB Intel Smart Cache, bis zu 4.60 GHz) |
| Operating system | Windows 11 Pro |
| Software |
| Pre-installed software | 1 month trial version for new Microsoft® 365 user |
| Processor |
| Processor family | Core i5 |
| Processor cores | Deka-Core (10 Cores) |
| Number of processors | 1 |
| Memory |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Maximum internal memory | 64 GB |
| Memory clock speed | PC5600 MHz |
| Internal memory type | DDR5 |
| Memory slots | 2 pc(s) |
| Storage |
| Total storage capacity | 500 GB |
| HDD interface | 2x M.2 2280 PCIe Gen4x4 |
| RAID levels | No RAID supported |
| SSD interface | PCIe (NVMe) |
| SSD capacity | 500 GB |
| HDD capacity | 1 x 500 GB - SSD |
| Number of storage drives supported | 2 |
| Storage media | SSD M.2 |
| Performance |
| Series | Business Medical |
| Design |
| Chassis type | Micro format |
| Certification | ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC |
| Keyboard form factor | Optional |
| Technical details |
| Localization | International |
| Packaging content |
| Included Accessories | Quick Start Guide, Power supply, powercord EU, VESA mounting kit |
| Weight & dimensions |
| Height | 4.83 cm |
| Width | 13 cm |
| Depth | 14 cm |
| Weight | 0.65 kg |
| Other features |
| Interface | Front: 1x USB 4.0 Type C, 2x USB 3.2 Type A, 1x Audio, Cardreader Rear: 1x USB 4.0 Type 4.0, 2x USB 3.2 Type A, 1x DP, 1x HDMI, 2x RJ45, DC-in, Kensington |
| Compatible operating systems | Windows 11 (64-Bit) |
| Cooling type | Active |
| Compliance industry standards | This appliance is classified as a Class B information technology equipment (ITE) and is intended primarily for use in residential and office environments. The CE mark confirms conformity with the following EU directives: (1) EMC Directive 2004/108/EC Electromagnetic Compatibility (2) Low Voltage Directive 2006/95/EC Electrical equipment designed for use within certain voltage limits. |
| Special features | TPM 2.0 Secure Boot Windows Autopilot-ready |
| Mouse |
| Mouse included | Optional |
| Graphics |
| On-board graphics adapter memory | Dynamisch GB |
| On-board graphics adapter maximum resolution | HDMI 4096x2160 @ 60Hz (4K), Display Port 3840x2160 @ 60Hz (4K) |
| Graphics card | Intel Iris Xe Graphics |
| On-board graphics card model | Integrated |
| Graphics adapter ports | 1x HDMI 2.1, 1x DP 1.4 |
| Power |
| Power source | External fanless power supply |
| Power consumption (standby) | Ø 2.5 Watt (S3 Mode, Suspend to RAM, WOL activated) 0,30 Watt Soft off (S5 Mode) |
| Maximum input power | 65 W |
| Nominal power | Ø 15 Watt Long Idle-Mode Ø 67 kWh a year (TEC = Typical Energy Consumption) Further information regarding Energy consumption see https://www.wortmann.de/green and/ or Quicklinks for this product (if available) |
| AC adapter input voltage | AC 100/240 V ( 50/60 Hz ) |
| Operational conditions |
| Operating temperature (T-T) | 5 °C - 35 °C |
| Maximum operating temperature range (T-T) | 35 °C |
| Recommended humidity operating range | 10 - 75% (non-condensing) |
| Network |
| Ethernet LAN | Netzwerkadapter - integriert |
| LAN controller | 1x Realtek RTL8111H, 10/100/1000 Mbps, WOL/PXE 1x Realtek RTL8125BG-CG with 10/100/1000/2500 MBit/s |
| Wi-Fi standards | Intel® Wi-Fi 6E AX211(Gig+) |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax Bluetooth 5.2 |
| Optical drive |
| Optical drive type | Ohne optisches Laufwerk |
| Input device |
| Device interface | USB Note: Keyboard not included |
