Caracteristicile managementului
Switch type	Unmanaged

Conexiune

Basic switching RJ-45 Ethernet ports quantity 5 Basic switching RJ-45 Ethernet ports type 2.5G Ethernet (100/1000/2500) 2.5G Ethernet (copper) ports quantity 5

Reţea

Ethernet LAN data rates 10,100,1000 Mbit/s Auto-negotiation Yes Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3p,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z Auto MDI/MDI-X Yes 10G support No

Transmisie de date

MAC address table 16000 entries Jumbo frames support Yes Switching capacity 25 Gbit/s Jumbo frames 10000 Forwarding rate 18.6 Mpps Packet buffer memory 1.5 MB Store-and-forward Yes

Design

Product colour Black Rack mounting No Certification CE, FCC ,RoHS LED indicators Yes

Managementul energiei

Input current 1 A Input voltage 12 V Power consumption (max) 12.11 W Power supply included Yes Power source DC

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -40 - 70 °C Heat dissipation 41.32 BTU/h Storage relative humidity (H-H) 5 - 90 %

Greutate şi dimensiuni

Width 209 mm Height 26 mm Depth 126 mm

Datele de ambalare

Package weight 870 g Quick start guide Yes Cables included LAN (RJ-45) Package width 240 mm Package depth 315 mm Package height 70 mm

Date logistice

Harmonized System (HS) code 85176990
