Descriere
Caracteristicile managementului |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Switch type | Managed |
| Switch layer | L2+ |
| MIB support | RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213 |
| ARP inspection | Yes |
| System event log | Yes |
| Traffic classification | Yes |
| Configuring Location Settings (CLI) | Yes |
| Cloud-managed | Yes |
Conexiune |
| SFP+ module slots quantity | 2 |
| Console port | RJ-45/micro-USB |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Power connector | AC-in jack |
| 2.5G Ethernet (copper) ports quantity | 8 |
Reţea |
| Flow control support | Yes |
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| Networking standards | IEEE 802.1D,IEEE 802.1s,IEEE 802.1w |
| VLAN support | Yes |
| Number of VLANs | 4000 |
| Link aggregation | Yes |
| Virtual LAN features | MAC address-based VLAN,Port-based VLAN,Private VLAN,Protocol-based VLAN,Tagged VLAN,Voice VLAN |
| 10G support | Yes |
| Spanning tree protocol | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| IP routing | Yes |
| Port mirroring | Yes |
| Head-of-line (HOL) blocking | Yes |
Transmisie de date |
| Jumbo frames support | Yes |
| MAC address table | 16000 entries |
| Switching capacity | 80 Gbit/s |
| Forwarding rate | 59.52 Mpps |
| Static route | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 12 MB |
| Number of static routes | 48 |
| Number of IP interfaces | 16 |
Securitate |
| Security algorithms | HTTPS,SSH,SSH-2,SSL/TLS |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| DHCP features | DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 snooping |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| BPDU filtering/protection | Yes |
| Authentication | MAC-based authentication,Port-based authentication |
| Loop protection | Yes |
| Authentication type | AAA,TACACS+ |
| IP-MAC-Port binding | Yes |
| Static port security | Yes |
| Queue scheduling algorithms | SP,WRR+SP,Weighted Round Robin (WRR) |
| Password protection | Yes |
Specificații (mod transmitere) multicast |
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | Yes |
Protocoale |
| Management protocols | SNMPv1/v2c/v3, SNTP |
| GARP VLAN Registration Protocol (GVRP) | Yes |
Design |
| Product colour | Black |
| Rack mounting | Yes |
| LED indicators | Yes |
| Number of fans | 2 fan(s) |
| Certification | CE, FCC, RoHS |
| Form factor | 1U |
Performanță |
| Fanless | Yes |
Managementul energiei |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 15 W |
| Power source | AC |
| Power supply included | Yes |
Conditii de mediu |
| Heat dissipation | 51.18 BTU/h |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
Greutate şi dimensiuni |
| Width | 294 mm |
| Depth | 180 mm |
| Height | 44 mm |
Datele de ambalare |
| Package weight | 2840 g |
| Package width | 528 mm |
| Package depth | 250 mm |
| Package height | 80 mm |
| Cables included | AC |
| Quick start guide | Yes |
| Package type | Box |
Date logistice |
| Harmonized System (HS) code | 85176990 |
