Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L3
MIB support	RFC1065, RFC1066, RFC1155, RFC1156, RFC2578 MIB Structure • RFC1212 Concise MIB Definitions • RFC1213 MIBII • RFC1215 MIB Traps Convention • RFC1493, RFC4188 Bridge MIB • RFC1157, RFC2571, RFC2572, RFC2573, RFC2574, RFC2575, RFC2576 SNMP MIB • RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC3636 SNMPv2 MIB • RFC271, RFC1757, RFC2819 RMON MIB • RFC2021 RMONv2 MIB • RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC3635 Etherlike MIB • RFC2668 802.3 MAU MIB • RFC2674, RFC4363 802.1p MIB • Interface Group MIB • RFC2618 RADIUS Authentication Client MIB • RFC4022 MIB for TCP • RFC4113 MIB for UDP • RFC2389 MIB for Diffserv. • RFC2620 RADIUS Accounting Client MIB • RFC2925 Ping & TRACEROUTE MIB • TFTP uploads and downloads (D-Link MIB) • Trap MIB (D-Link MIB) • RFC4265 IPv6 MIB • RFC4266 ICMPv6 MIB • Entity MIB • VRRP MIB • RIPv2 MIB • RFC1850, RFC5643 OSPF MIB • RFC4293 IPv6 SNMP Mgmt Interface MIB • DDM MIB (D-Link MIB) • Private MIB • MIB for D-Link Zone Defense • RFC3621 Power Ethernet MIB • DDP MIB • LLDP-MED MIB
ARP inspection	Yes
System event log	Yes

Conexiune

Fiber optic connector SFP+ USB 2.0 ports quantity 1 SFP+ module slots quantity 4 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 24 Power connector AC-in jack

Reţea

Flow control support Yes Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3at,IEEE 802.3az,IEEE 802.3x VLAN support Yes Number of VLANs 4000 Link aggregation Yes Copper ethernet cabling technology 10BASE-T,100BASE-T,1000BASE-T Virtual LAN features MAC address-based VLAN,Port-based VLAN,Private VLAN,Tagged VLAN,Voice VLAN 10G support Yes Spanning tree protocol Yes Broadcast storm control Yes Port mirroring Yes Head-of-line (HOL) blocking Yes

Transmisie de date

Jumbo frames support Yes MAC address table 16384 entries Switching capacity 168 Gbit/s Forwarding rate 125 Mpps Packet buffer memory 2 MB Number of queues 8

Securitate

Security algorithms SNMP,SNMPv3,SSH-2,SSL/TLS Access Control List (ACL) Yes DHCP features DHCP client,DHCP relay,DHCP server,DHCP snooping IGMP snooping Yes SSH/SSL support Yes BPDU filtering/protection Yes Authentication Auto VLAN,MAC-based authentication,Port-based authentication Loop protection Yes Queue scheduling algorithms Deficit weighted round robin (DWRR),SP,WRR+SP,Weighted Round Robin (WRR) Password protection Yes Access Control List (ACL) ingress 2048 Access Control List (ACL) egress 512

Specificații (mod transmitere) multicast

Multicast support Yes Multicast features Controllable multicast

Protocoale

Routing protocols RIP GARP VLAN Registration Protocol (GVRP) Yes

Design

Product colour Grey Rack mounting Yes LED indicators Yes Number of fans 3 fan(s) Certification FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI Stackable Yes

Performanță

Mean time between failures (MTBF) 279418 h Noise level 53.4 dB Physical stacking (units) 9 Virtual stacking (units) 32

Managementul energiei

AC input frequency 50 - 60 Hz AC input voltage 100 - 240 V Power consumption (typical) 38.74 W Power consumption (max) 454.55 W Redundant power supply (RPS) support Yes Power source DC

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 24 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 370 W

Conditii de mediu

Heat dissipation 1550.92 BTU/h Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -40 - 70 °C Storage relative humidity (H-H) 5 - 90 %

Greutate şi dimensiuni

Width 440 mm Depth 430 mm Height 44 mm Weight 5600 g
