Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2/L3
MIB support	Yes

Conexiune

SFP module slots quantity 2 Console port RJ-45 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 8

Reţea

Ethernet LAN data rates 10,100,1000 Mbit/s Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Full duplex Yes Auto MDI/MDI-X Yes Virtual LAN features Tagged VLAN Half duplex Yes

Transmisie de date

MAC address table 8000 entries Switching capacity 20 Gbit/s Forwarding rate 14.88 Mpps Packet buffer memory 4.1 MB Store-and-forward Yes

Securitate

Access Control List (ACL) Yes DHCP features DHCP relay,DHCP snooping IGMP snooping Yes SSH/SSL support Yes IP-MAC-Port binding Yes Static port security Yes

Specificații (mod transmitere) multicast

Multicast support Yes Multicast Listener Discovery (MLD) snooping Yes

Design

Product colour Black Rack mounting Yes LED indicators Activity,Link,Power,Speed Form factor 1U

Performanță

Mean time between failures (MTBF) 277967 h Internal memory 256 MB Flash memory 32 MB Memory type DDR3-SDRAM

Managementul energiei

Power consumption (typical) 2.5 W Power consumption (max) 81.9 W DC input voltage 54 V Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 8 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 65 W

Conditii de mediu

Heat dissipation 279.59 BTU/h Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -40 - 70 °C Storage relative humidity (H-H) 5 - 90 %

Greutate şi dimensiuni

Width 280 mm Depth 126 mm Height 44 mm Weight 950 g

Date logistice

Harmonized System (HS) code 85176990
