| Network |
| Networking standards | IEEE 802.3af,IEEE 802.3at |
| Flow control support | Y |
| Port mirroring | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Virtual LAN features | Voice VLAN |
| Full duplex | Y |
| Auto MDI (MDI-X) | Y |
| Number of VLANs | 4094 |
| Spanning tree protocol | Y |
| Head-of-line (HOL) blocking | Y |
| VLAN support | Y |
| 10G support | Y |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Cable types supported | Cat5,Cat5e |
| Technical details |
| Vendor | D-Link |
| Pallet gross width | 1200 mm |
| Pallet gross length | 1100 mm |
| Shipping (inner) case width | 478 mm |
| Shipping (inner) case length | 585 mm |
| Shipping (inner) case height | 428 mm |
| Shipping (inner) case gross weight | 25467 g |
| Products per shipping (inner) case | 5 pc(s) |
| Shipping (inner) case net weight | 19299 g |
| Pallet gross weight (air) | 425972 g |
| Master (outer) cases per pallet (air) | 16 pc(s) |
| Products per pallet (air) | 80 pc(s) |
| Pallet height (air) | 1847 mm |
| Pallet gross weight (sea) | 425972 g |
| Master (outer) cases per pallet (sea) | 16 pc(s) |
| Products per pallet (sea) | 80 pc(s) |
| Pallet height (sea) | 1847 mm |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45 |
| Optical fiber |
| Fiber ethernet cabling technology | 100BASE-FX,1000BASE-LHX,1000BASE-X,1000BASE-LX,1000BASE-SX,1000BASE-ZX |
| Weight & dimensions |
| Height | 44 mm |
| Width | 440 mm |
| Depth | 250 mm |
| Weight | 3460 g |
| Design |
| LED indicators | Activity, Link, Power, Speed |
| Product colour | Black |
| Certification | CB, UL, BSMI, CCC |
| Electromagnetic compatibility | CE A, VCCI A, FCC A, IC, BSMI |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 370 W |
| Power over Ethernet (PoE) power per port | 15.4 W |
| Power over Ethernet (PoE) | Y |
| Performance |
| Noise level | 50.8 dB |
| Firmware upgradeable | Y |
| Mean time between failures (MTBF) | 463430.16 h |
| Flash memory | 64 MB |
| Internal memory | 2048 MB |
| Memory type | DDR3-SDRAM |
| Multicast features |
| Multicast support | Y |
| Power |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 455.1 W |
| Power supply included | Y |
| Operational conditions |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Heat dissipation | 1551.891 BTU/h |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -20 - 70 °C |
| Data transmission |
| Packet buffer memory | 12 MB |
| Number of static routes | 124 |
| Switching capacity | 128 Gbit/s |
| Jumbo frames | 12000 |
| Jumbo frames support | Y |
| Static route | Y |
| Store-and-forward | Y |
| MAC address table | 16000 entries |
| Forwarding rate | 95.24 Mpps |
| Packaging data |
| Package depth | 563 mm |
| Package height | 89 mm |
| Package width | 393 mm |
| Package weight | 4757 g |
| Security |
| Loop protection | Y |
| IP-MAC-Port binding | Y |
| Access Control List (ACL) rules | 768 |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| Access Control List (ACL) | Y |
| DHCP features | DHCP server,DHCP snooping |
| Security algorithms | EAP,LEAP,MD5,PEAP,SSH,SSL/TLS,TTLS |
| IGMP snooping | Y |
| Management features |
| ARP inspection | Y |
| MIB support | RFC2893, RFC4213, RFC4291, RFC2464, RFC2462, RFC4862, RFC2461, RFC4861, RFC2573, RFC1321, RFC2284, RFC2865, RFC2716, RFC3580, RFC826, RFC2463, RFC4443, RFC792, RFC793, RFC768, RFC791, RFC2389, RFC4113, RFC4022, RFC2618, RFC2674, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2021, RFC271, RFC1757, RFC2819, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC2573, RFC2575, RFC2576, RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2620, |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Configuring Location Settings (CLI) | Y |
| Web-based management | Y |
| System event log | Y |
| Switch type | Managed |
