Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2

Conexiune

Gigabit Ethernet (copper) ports quantity 8 SFP module slots quantity 2 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 8 Power connector DC-in jack

Reţea

Flow control support Yes Networking standards IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x Link aggregation Yes Full duplex Yes Copper ethernet cabling technology 10BASE-T,100BASE-T,1000BASE-T Auto MDI/MDI-X Yes 10G support No Port mirroring Yes Cable types supported Cat5,Cat5e

Transmisie de date

MAC address table 8000 entries Switching capacity 20 Gbit/s Forwarding rate 14.88 Mpps Packet buffer memory 0.512 MB Store-and-forward Yes

Securitate

MAC address filtering Yes Access Control List (ACL) Yes

Specificații (mod transmitere) multicast

Multicast support Yes

Design

Product colour Black Rack mounting Yes LED indicators Yes Certification EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC Form factor 1U Stackable Yes

Performanță

Mean time between failures (MTBF) 729258 h

Managementul energiei

Power consumption (max) 80.6 W

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 2 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 78 W Power over Ethernet (PoE) ports quantity 8

Conditii de mediu

Heat dissipation 373.96 BTU/h Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -20 - 70 °C Storage relative humidity (H-H) 0 - 95 %

Greutate şi dimensiuni

Width 280 mm Depth 126 mm Height 44 mm Weight 950 g

Datele de ambalare

Package weight 2210 g Package width 288 mm Package depth 331 mm Package height 72 mm
