Caracteristicile managementului
Quality of Service (QoS) support	Yes
Switch type	Unmanaged
Switch layer	L2

Conexiune

Basic switching RJ-45 Ethernet ports quantity 5 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Gigabit Ethernet (copper) ports quantity 5

Reţea

Ethernet LAN data rates 10,100,1000 Mbit/s Networking standards IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x Copper ethernet cabling technology 10BASE-T,100BASE-TX,1000BASE-T Auto MDI/MDI-X Yes 10G support No Flow control support Yes Full duplex Yes Head-of-line (HOL) blocking Yes Half duplex Yes

Transmisie de date

MAC address table 2048 entries Jumbo frames support Yes Switching capacity 10 Gbit/s Jumbo frames 9216 Forwarding rate 7.4 Mpps Number of queues 4

Securitate

Queue scheduling algorithms Weighted Round Robin (WRR)

Design

Product colour Grey Rack mounting Yes Certification UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B LED indicators Yes Form factor 1U

Performanță

Mean time between failures (MTBF) 4243002 h

Managementul energiei

Power supply included Yes DC input voltage 12 V Number of power supply units 1 Redundant power supply (RPS) support No

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -20 - 70 °C Heat dissipation 9.34 BTU/h Storage relative humidity (H-H) 5 - 90 %

Greutate şi dimensiuni

Width 110 mm Height 30 mm Depth 75 mm Weight 230 g

Datele de ambalare

Quick start guide Yes

Date logistice

Harmonized System (HS) code 85176990
