Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2/L3
MIB support	Yes
ARP inspection	Yes
Configuring Location Settings (CLI)	Yes

Conexiune

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 48 Installed SFP+ modules quantity 4

Reţea

Flow control support Yes Ethernet LAN data rates 1000 Mbit/s Networking standards IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ad,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Spanning tree protocol Yes Broadcast storm control Yes Port mirroring Yes Head-of-line (HOL) blocking Yes

Transmisie de date

Jumbo frames support Yes Static route Yes Jumbo frames 9000

Securitate

Security algorithms HTTPS,SSH,SSL/TLS MAC address filtering Yes Access Control List (ACL) Yes IGMP snooping Yes SSH/SSL support Yes

Specificații (mod transmitere) multicast

Multicast support Yes

Design

Product colour White LED indicators Yes Housing material Metal Country of origin China Reset button Yes

Performanță

Internal memory 1024 MB Flash memory 512 MB Processor frequency 1400 MHz

Managementul energiei

Power plug type Type C Power source AC Power supply included Yes

Conditii de mediu

Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -25 - 70 °C Storage relative humidity (H-H) 10 - 90 %

Greutate şi dimensiuni

Width 350.012 mm Depth 444.5 mm Height 43.942 mm

Datele de ambalare

Package weight 6961.45 g Package width 480.822 mm Package depth 571.754 mm Package height 94.996 mm
