Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2/L3
MIB support	Yes
Configuring Location Settings (CLI)	Yes

Conexiune

SFP module slots quantity 4 Console port RJ-45/USB Type-C Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 24

Reţea

Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3an,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Link aggregation Yes Virtual LAN features Private VLAN,Voice VLAN Spanning tree protocol Yes Broadcast storm control Yes Rate limiting Yes Port mirroring Yes Head-of-line (HOL) blocking Yes Cable types supported Cat5e Policy-based routing Yes QinQ implementation Selective QinQ

Transmisie de date

Jumbo frames support Yes MAC address table 16000 entries Switching capacity 56 Gbit/s Static route Yes Jumbo frames 9000 Packet buffer memory 1.5 MB Number of queues 8 Number of static routes 990

Securitate

Security algorithms HTTPS,SNMP,SNMPv2,SNMPv3,SSH,SSH-2 Access Control List (ACL) Yes DHCP features DHCP auto-config,DHCP client,DHCP relay,DHCP server,DHCP snooping IGMP snooping Yes SSH/SSL support Yes Authentication MAC-based authentication,Web-based authentication Authentication type RADIUS,TACACS+ Access Control List (ACL) rules 1024 Queue scheduling algorithms Weighted Round Robin (WRR) DoS attack prevention Yes IGMP proxy Yes

Specificații (mod transmitere) multicast

Multicast support Yes

Protocoale

GARP VLAN Registration Protocol (GVRP) Yes IPv4 & IPv6 features ICMPv6,IPv6 SNMP,IPv6 SSH,IPv6 TFTP,IPv6 Telnet

Design

Product colour Grey Rack mounting Yes Certification UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A Country of origin China Reset button Yes

Performanță

Mean time between failures (MTBF) 698220 h Noise level 34.8 dB Plug and Play Yes Internal memory 1000 MB Flash memory 512 MB Memory type DDR4-SDRAM Built-in processor Yes Processor frequency 1.4 MHz

Managementul energiei

AC input frequency 50/60 Hz AC input voltage 100 - 220 V Power consumption (typical) 37.2 W Power plug type Type C Power source AC

Curent pe cablu net (PoE)

Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 370 W Power over Ethernet (PoE) ports quantity 24

Conditii de mediu

Heat dissipation 1542.3 BTU/h Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -25 - 70 °C Storage relative humidity (H-H) 10 - 90 %

Greutate şi dimensiuni

Width 350.012 mm Depth 444.5 mm Height 43.942 mm Weight 4600 g

Datele de ambalare

Package weight 7120.18 g Package width 512.064 mm Package depth 575.056 mm Package height 107.95 mm
