Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L3
ARP inspection	Yes
System event log	Yes
Traffic classification	Yes
Configuring Location Settings (CLI)	Yes
Traffic shaping	Yes

Conexiune

USB 2.0 ports quantity 1 SFP module slots quantity 4 Console port RJ-45 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 16

Reţea

Flow control support Yes Networking standards IEEE 1588,IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.1ag,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.2,IEEE 802.3ab,IEEE 802.3ac,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Number of VLANs 4094 Link aggregation Yes Full duplex Yes Virtual LAN features Private VLAN,Tagged VLAN 10G support No Spanning tree protocol Yes Broadcast storm control Yes Port mirroring Yes Policy-based routing Yes

Transmisie de date

Jumbo frames support Yes MAC address table 16000 entries Switching capacity 40 Gbit/s Forwarding rate 29.7 Mpps Jumbo frames 9000 Packet buffer memory 1.5 MB Number of queues 8

Securitate

MAC address filtering Yes Access Control List (ACL) Yes DHCP features DHCP relay,DHCP server,DHCP snooping,DHCPv6 relay,DHCPv6 server IGMP snooping Yes BPDU filtering/protection Yes Authentication Guest VLAN,MAC-based authentication,Port-based authentication,Web-based authentication Password protection Yes

Specificații (mod transmitere) multicast

Multicast support Yes

Protocoale

Routing protocols BGP,OSPF,RIP

Design

Product colour Grey Rack mounting No LED indicators Yes Housing material Aluminium,Metal Certification CE, FCC, ICES, RCM, TEC8, UL, VCCI RoHS, China-RoHS, WEEE Wall mountable Yes International Protection (IP) code IP30 Stackable No Electromagnetic compatibility EN 55024, EN 61000-6-2 DIN rail mounting Yes

Performanță

Internal memory 512 MB Flash memory 128 MB Memory type DDR-SDRAM Fanless Yes Export Control Classification Number (ECCN) 5A992C

Managementul energiei

Power consumption (max) 271 W DC input voltage 18 - 57 V Redundant power supply (RPS) support Yes Power supply included No

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 16 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 240 W Power over Ethernet (PoE) power per port 15 W

Conditii de mediu

Heat dissipation 105.8 BTU/h Operating temperature (T-T) -40 - 75 °C Operating relative humidity (H-H) 5 - 95 % Storage temperature (T-T) -40 - 85 °C Operating altitude 0 - 3000 m Storage relative humidity (H-H) 5 - 90 %

Greutate şi dimensiuni

Width 91 mm Depth 139 mm Height 153 mm Weight 2340 g

Date logistice

Harmonized System (HS) code 85176990
