Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L3
ARP inspection	Yes
System event log	Yes
Traffic classification	Yes
Configuring Location Settings (CLI)	Yes

Conexiune

Gigabit Ethernet (copper) ports quantity 24 Console port USB Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 20 Installed SFP+ modules quantity 4

Reţea

Ethernet LAN data rates 10,100,1000,2500,5000 Mbit/s Networking standards IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Number of VLANs 4094 Link aggregation Yes Copper ethernet cabling technology 10BASE-T,100BASE-TX,1000BASE-T Virtual LAN features Port-based VLAN,Private VLAN,Tagged VLAN,Voice VLAN 10G support Yes Spanning tree protocol Yes Port mirroring Yes

Transmisie de date

Jumbo frames support Yes MAC address table 16000 entries Switching capacity 160 Gbit/s Forwarding rate 119 Mpps Static route Yes Jumbo frames 10000 Packet buffer memory 1.5 MB Number of queues 8

Securitate

Security algorithms 3DES,AES,MD5,SHA-1,SHA-2,SHA-256,SHA-384,SHA-512,SSH,SSH-2,SSL/TLS MAC address filtering Yes Access Control List (ACL) Yes DHCP features DHCP Option 82,DHCP relay,DHCP snooping,DHCPv6 client,DHCPv6 relay IGMP snooping Yes BPDU filtering/protection Yes Authentication MAC-based authentication,Port-based authentication,Web-based authentication Loop protection Yes Queue scheduling algorithms SP,WRR+SP,Weighted Round Robin (WRR)

Specificații (mod transmitere) multicast

Multicast support Yes

Protocoale

Management protocols SNMPv1, v2c, v3 Routing protocols RIP,RIP-2,RIPng

Design

Product colour Grey Rack mounting Yes LED indicators Yes Certification EN55024 FCC Class A, EN55032 Class A, EN61000-3-2, EN61000-3-3, VCCI Class A, RCM EN55024, EN61000-3-levels 2 UL60950-1, CSA-C22.2 No. 60950-1, EN60950-1, UL62368-1 cUL, cULus Form factor 1U Stackable Yes

Performanță

Noise level 42 dB Internal memory 1000 MB Flash memory 256 MB Memory type DDR3-SDRAM Physical stacking (units) 2

Managementul energiei

Power consumption (typical) 70 W Power consumption (max) 510 W

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 24 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 370 W Power over Ethernet (PoE) power per port 30 W

Conditii de mediu

Heat dissipation 1741 BTU/h Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 5 - 90 % Storage temperature (T-T) -25 - 70 °C Operating altitude 0 - 3000 m Storage relative humidity (H-H) 5 - 95 %

Greutate şi dimensiuni

Width 441 mm Depth 421 mm Height 44 mm Weight 5600 g

Sustenabilitate

Sustainability certificates RoHS,TUV Sustainability compliance Yes

Datele de ambalare

Package weight 7600 g Package width 563 mm Package depth 534 mm Package height 128 mm
