Design |
| Form factor | Tube/dome |
| Product colour | |
| Built-in reflector | N |
| Housing material | Metal, Plastic |
| ROM capacity | 4000 MB |
| RAM capacity | 1 GB |
| Appliance placement | Ceiling/wall |
| Integrated antenna | N |
| Motion sensor | Y |
Power |
| Power over Ethernet (PoE) | Y |
| Power source type | DC, PoE |
| Power consumption (typical) | 9 W |
| Power consumption (max) | 20 W |
| Built-in battery | N |
| DC output voltage | 12V |
Operational conditions |
| Operating temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 70 °C |
| International Protection (IP) code | IP66 |
| Overvoltage protection | Y |
Management features |
| Reset button | N |
| Dedicated application | DMSS (Android, iOS) |
| Number of users | 20 user(s) |
| Cloud-managed | Y |
| Smart notifications | Y |
| On Screen Display (OSD) languages | |
| Embedded web server | Y |
Weight & dimensions |
| Length | 270,4 mm |
| Weight | 2.4 kg |
| Package weight | 3.9 kg |
| Product diameter | 160 mm |
Network |
| Bluetooth | N |
| Maximum data transfer rate | 100 Mbit/s |
| MIMO | N |
| Supported network protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPoE,DDNS, FTP, P2P |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Access Point | N |
| Number of users | 20 user(s) |
Performance |
| Connectivity technology | Wired |
| Type | IP security camera |
| Noise reduction technology | 3D-DNR digital noise reduction |
| Wide Dynamic Range (WDR) | Y |
| Remote control of PTZ cameras | Yes |
| PTZ protocols | |
| Motion detection | Yes |
| Region of Interest (ROI) encoding | Y |
| Onvif standard | Yes |
| Electronic fog removal | Yes |
| Day/night mode | Y |
| Infrared (IR) cut-off filter | Y |
| Mirror display mode | Y |
| Privacy masking | Y |
| White balance | Auto |
| Light compensation | BLC/HLC |
| Placement supported | Indoor/outdoor |
| Intelligent Video Surveillance (IVS) system features | |
| SMD | Yes |
Packaging content |
| Mounting kit | Y |
| Number of cameras | 1 |
| Instruction sheet | Y |
| Memory card included | N |
| Mounting template | Y |
Audio |
| Sound detection | Yes |
| Audio recording | Y |
| Built-in speaker(s) | N |
Storage |
| Cloud recording | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Built-in HDD | N |
| Local recording | Yes |
| Maximum memory card size | 512 GB |
Ports & interfaces |
| RJ-45 ports quantity | 1 |
| Alarm input/output | Y |
| Audio input | 1 |
| Audio output | 1 |
| Memory card slot(s) | Y |
Camera |
| Angle of rotation | 360° |
| Detection distance (humans) | 2161,4 m |
| Tilt angle | 90° |
| Recognition distance (humans) | 432,3 m |
| Camera tilt control | Y |
| Identification distance (humans) | 216,1 m |
Image sensor |
| Image sensor size | 1/2.8" |
| Sensor type | Progressive Scan CMOS |
| Number of sensors | 1 |
Video |
| Maximum resolution | 2560 x 1440 pixels |
| Supported video modes | |
| Focus | Automatic / semi-automatic / manual |
| Digital zoom | 16x |
| Total megapixels | 4 MP |
| Optical zoom | 25x |
| Video compression formats | |
| Maximum frame rate | 30 fps |
Night vision |
| Built-in IR LEDs | Yes |
| Night vision distance | 100 m |
| Number of infrared LEDs | 4 |
| Night vision | Y |
Lens system |
| Lens viewing angle, vertical | 30.4° – 1.9° |
| Lens diaphragm | F/1.6 – F/3.6 |
| Focal length range | 5 – 125 mm |
| Lens viewing angle, diagonal | 59.3° – 3.9° |
| Lens viewing angle, horizontal | 53.1° – 3.4° |
| Lens type | Varifocal |
