Technical details |
| Supported memory types | DDR4-SDRAM |
| Product type | Processor |
| Status | Launched |
| Memory speed (max) | 2400 MHz |
| Launch date | Q1''20 |
| Number of UPI links | 2 |
Processor |
| Processor lithography | 14 nm |
| Processor ARK ID | 197100 |
| Processor boost frequency | 3.5 GHz |
| Processor manufacturer | Intel |
| Component for | Server/workstation |
| Processor codename | Cascade Lake |
| Processor threads | 24 |
| Processor model | 4214R |
| Processor cores | 12 |
| Thermal Design Power (TDP) | 100 W |
| Processor socket | FCLGA3647 |
| Processor cache | 16.5 MB |
| Processor family | Intel Xeon Silver |
| Processor operating modes | 64-bit |
| Processor base frequency | 2.4 GHz |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Cooler included | N |
| Box | N |
Graphics |
| Discrete graphics card | N |
| On-board graphics card | N |
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
Features |
| Supported instruction sets | |
| Execute Disable Bit | Y |
| Embedded options available | Y |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 48 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Market segment | Server |
| Scalability | 2S |
| Harmonized System (HS) code | 8542310001 |
| PCI Express CEM revision | 3.0 |
Memory |
| ECC | Y |
| Memory channels | Hexa-channel |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Maximum internal memory supported by processor | 1024 GB |
Operational conditions |
| |
| |
Weight & dimensions |
| |
| |
Packaging data |
| Package height | 112 mm |
| Package depth | 137 mm |
| Package width | 43 mm |
Processor special features |
| Enhanced Intel SpeedStep Technology | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Intel 64 | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel Trusted Execution Technology | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® Transactional Synchronization Extensions | Y |
| Intel® Speed Shift Technology | Y |
| Intel® Optane™ DC Persistent Memory technology | N |
| Intel Turbo Boost Max Technology 3.0 | N |
| Intel® Deep Learning Boost (Intel® DL Boost) | Y |
| Intel® Volume Management Device (VMD) | Y |
| Intel® vPro™ Platform Eligibility | Y |
| Intel® Run Sure Technology | N |
| Intel® Optane™ DC Persistent Memory Supported | N |
| Mode-based Execute Control (MBE) | Y |
| Intel® Resource Director Technology (Intel® RDT) | Y |
| AVX-512 Fused Multiply-Add (FMA) units | 1 |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | N |
| Intel Speed Select Technology (SST) | N |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | N |
Other features |
| |
| |
