Procesor
Processor cores	14
Processor family	Intel® Core™ i5
Processor model	i5-14600K
Processor cache	24 MB
Processor threads	20
Processor socket	LGA 1700
Processor operating modes	64-bit
Processor cache type	Smart Cache
Processor boost frequency	5.3 GHz
Processor codename	Raptor Lake
Processor generation	Intel Core i5-14xxx
Stepping	B0
Processor manufacturer	Intel
Memory bandwidth supported by processor (max)	89.6 GB/s
Cooler included	No
Box	Yes
Processor ARK ID	236799
Processor base power	125 W
Maximum number of DMI lanes	8
Performance-core base frequency	3.5 GHz
Performance cores	6
Maximum turbo power	181 W
Performance-core boost frequency	5.3 GHz
Efficient-core base frequency	2.6 GHz
Efficient-core boost frequency	4 GHz
Efficient cores	8

Memorie

Memory types supported by processor DDR4-SDRAM,DDR5-SDRAM Maximum internal memory supported by processor 192 GB ECC Yes Memory channels Dual-channel Memory bandwidth (max) 89.6 GB/s Non-ECC Yes

Grafică

On-board graphics card Yes On-board graphics card model Intel UHD Graphics 770 Discrete graphics card No On-board graphics card base frequency 300 MHz On-board graphics card dynamic frequency (max) 1550 MHz On-board graphics card OpenGL version 4.5 Number of displays supported (on-board graphics) 4 On-board graphics card DirectX version 12.0 Discrete graphics card model Not available On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels On-board graphics card ID 0xA780 On-board graphics card outputs supported Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1 Number of execution units 32 Multi-Format Codec Engines 2

Caracteristici

Maximum number of PCI Express lanes 20 Scalability 1S Embedded options available No Supported instruction sets AVX 2.0,SSE4.1,SSE4.2 Execute Disable Bit Yes Idle States Yes Thermal Monitoring Technologies Yes PCI Express configurations 1x16+1x4,2x8+1x4 PCI Express slots version 4.0,5.0 Market segment Desktop CPU configuration (max) 1 Export Control Classification Number (ECCN) 5A992C Commodity Classification Automated Tracking System (CCATS) 740.17B1 Thermal solution specification PCG 2020A Use conditions Workstation,PC/Client/Tablet Direct Media Interface (DMI) Revision 4.0

Caracteristici speciale procesor

Intel Virtualization Technology (VT-x) Yes Intel 64 Yes Enhanced Intel SpeedStep Technology Yes Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel® Turbo Boost Technology 2.0 Intel® Hyper Threading Technology (Intel® HT Technology) Yes Intel® AES New Instructions (Intel® AES-NI) Yes Intel® Secure Key Yes Intel® OS Guard Yes Intel® Speed Shift Technology Yes Intel® Volume Management Device (VMD) Yes Intel® Deep Learning Boost (Intel® DL Boost) Yes Mode-based Execute Control (MBE) Yes Intel® Boot Guard Yes Intel® Clear Video HD Technology (Intel® CVT HD) Yes Intel® Quick Sync Video Technology Yes Intel® Control-flow Enforcement Technology (CET) Yes Intel® Thread Director Yes Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes Intel® Standard Manageability (ISM) Yes

Conditii de mediu

Tjunction 100 °C

Date logistice

Harmonized System (HS) code 8542310001

Detalii tehnice

Status Launched Launch date Q4''23 OpenCL version 3.0

Greutate şi dimensiuni

Processor package size 45 x 37.5 mm

Alte caracteristici

Maximum internal memory 192 GB Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1 L2 cache 20480 KB
