Performanță
Connectivity technology	Wired
Type	IP security camera
Placement supported	Outdoor
Certification	EN 55032 A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-003 A, VCCI A, RCM AS/NZS CISPR 32 A, KCC KN32 A, KN35, EAC IEC/EN/UL 62368-1, IEC/EN/UL 60950-22 IS 13252 EN 50581, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10 body, IK08, NEMA 250 4X, NEMA TS 2 NIST SP500–267 EN/IEC 62471
PTZ control	Yes
Day/night mode	Yes
Languages support	CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN,KOR,POR,RUS
Number of languages	11
Infrared (IR) cut-off filter	Yes

Design

Product colour Grey Form factor Bullet Mounting type Ceiling/Wall International Protection (IP) code IP66 Housing material Plastic IK code IK08

Aparat de fotografiat

Camera shutter speed 1/66500 - 1 s Minimum illumination 0.03 lx Lens viewing angle, vertical 9.6 ° Lens viewing angle, horizontal 16 °

Senzor de imagine

Sensor type CMOS Optical sensor size 1/2.8 " Progressive scan Yes Number of sensors 1

Sistem de lentile

Maximum aperture number 4.1 Focal length range 18 - 137 mm Zoom capability Yes Number of lenses 1 Optical zoom 8 x Minimum aperture number 2.9

Vizibilitate nocturnă

Night vision Yes LED type IR Night vision distance 50 m Infra-red wavelength 850 nm

Video

Maximum resolution 1920 x 1080 pixels Frame rate 60 fps Video compression formats AVC,H.264,M-JPEG Image quality adjustment Brightness,Contrast,Saturation,Sharpness Bit rate control Variable Bit Rate (VBR)

Audio

Audio formats supported AAC Voice codecs G.711,G.726,PCM

Reţea

Ethernet LAN Yes Supported network protocols IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP Networking standards IEEE 802.1x,IEEE 802.3af,IEEE 802.3at Ethernet interface type Fast Ethernet Wi-Fi No Quality of Service (QoS) support Yes Bluetooth No

Medii de stocare

Compatible memory cards MicroSD (TransFlash),MicroSDHC,MicroSDXC Card reader integrated Yes Flash memory 512 MB Internal memory 1024 MB Built-in HDD No

Conexiune

Ethernet LAN (RJ-45) ports 1 Microphone in Yes Terminal block port Yes

Securitate

IP address filtering Yes HTTPS encryption Yes Password protection Yes Security algorithms EAP-TLS Detection distance 100 m

Managementul energiei

Power source type DC,PoE Power consumption (Power over Ethernet (PoE)) 12.95 W

Conditii de mediu

Operating temperature (T-T) -40 - 60 °C Operating relative humidity (H-H) 10 - 100 % Storage temperature (T-T) -40 - 65 °C

Greutate şi dimensiuni

Weight 2400 g Diameter 147 mm Length 439 mm

Conţinutul de ambalaje

Number of cameras 1 Cables included LAN (RJ-45)

Date logistice

Harmonized System (HS) code 85258900
