Descriere
Performanță |
| Connectivity technology | Wired |
| Placement supported | Indoor |
| Type | IP security camera |
| Certification | 55032 Class A, EN 50121-4, EN 55024, EN 61000-6-1, EN 61000-6-2, IEC 62236–4, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, IEC/EN/UL 62368-1, IEC 62471, IEC 60068–2–1, IEC 60068–2–2, IEC 60068–2–14, IEC 60068–2–27, IEC 60068–2–6, IEC/EN 60529 IP42, IEC/EN 62262 IK08, NIST SP500-267 |
| PTZ control | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Languages support | CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN,KOR,POR,RUS |
| Number of languages | 11 |
| PTZ modes | Digital PTZ |
Design
Product colour Black,White Form factor Dome Mounting type Ceiling/Wall International Protection (IP) code IP42 Housing material Aluminium Protection features Dust resistant,Shock resistant,Water resistant IK code IK08
Aparat de fotografiat
Minimum illumination 0.05 lx Camera shutter speed 1/10000 - 1/5 s Tilt angle range -40 - 65 ° Pan range -180 - 180 ° Camera tilt control Yes Camera pan control Yes Angle of rotation 210 ° Lens viewing angle, horizontal 100 ° Lens viewing angle, vertical 72 °
Senzor de imagine
Sensor type CMOS Optical sensor size 1/2.5 " Number of sensors 1 Progressive scan Yes
Sistem de lentile
Maximum aperture number 2 Number of lenses 1 Zoom capability Yes Focal length range 3 - 6 mm
Vizibilitate nocturnă
Night vision Yes LED type IR Night vision distance 15 m Infra-red wavelength 850 nm
Video
Maximum resolution 2048 x 1536 pixels Frame rate 60 fps Video compression formats AVC,H.264,H.265,MPEG4 Total megapixels 3 MP Supported graphics resolutions 320 x 240,1920 x 1080 (HD 1080),2048 x 1536 (QXGA) Video streaming Yes Supported video modes 720p,1080p Image quality adjustment Brightness,Contrast,Sharpness Text caption overlay Yes Bit rate control Variable Bit Rate (VBR) Privacy masking Yes
Reţea
Ethernet LAN Yes Supported network protocols IPv4, IPv6 USGv6, HTTP, HTTPS , SSL/TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, DHCP, SOCKS, SSH, HDMI 1.4b, LLDP Networking standards IEEE 802.1x,IEEE 802.3af,IEEE 802.3at Quality of Service (QoS) support Yes Streaming method Multicast
Medii de stocare
Compatible memory cards MicroSD (TransFlash),MicroSDHC,MicroSDXC Card reader integrated Yes Flash memory 512 MB
Conexiune
Ethernet LAN (RJ-45) ports 1 HDMI ports quantity 1
Securitate
Video motion detection Yes HTTPS encryption Yes IP address filtering Yes Password protection Yes Alert notification type E-mail
Caracteristicile managementului
Remotely operated Yes
Managementul energiei
Power source type PoE Power consumption (max) 8.1 W Power consumption (Power over Ethernet (PoE)) 4.6 W
Conditii de mediu
Operating temperature (T-T) 0 - 45 °C Storage temperature (T-T) -40 - 65 °C Operating relative humidity (H-H) 10 - 85 %
Greutate şi dimensiuni
Weight 370 g Height 71 mm Width 121 mm Depth 121 mm
Conţinutul de ambalaje
Number of cameras 1 Manual Yes
Date logistice
Harmonized System (HS) code 85258900
