Performanță
Product colour	Graphite
PTZ control	Yes
Tilt angle range	-15 - 15 °
Pan range	-25 - 25 °

Video

Supported video modes 576p,720p,900p,1440p,2160p HD type 4K Ultra HD Maximum frame rate 30 fps Maximum video resolution 3840 x 2160 pixels

Audio

Noise reduction Yes Echo cancellation Yes Built-in speaker(s) Yes RMS rated power 8 W Microphone range 4.5 m Output level 92/99 dB Output voltage Total Harmonic Distortion (THD) 2 % Line-out impedance 4 Ω Audio beamforming Yes Sample rates 0 - 48 kHz Driver diameter 70 mm

Conexiune

HDMI ports quantity 3 Ethernet LAN (RJ-45) ports 1 DC-in jack Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3 USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1 USB connector type USB Type-A,USB Type-C HDMI output ports quantity 2 HDMI input ports quantity 1

Modul interfață

Interface module RJ-45 ports quantity 1

Reţea

Ethernet LAN Yes Wi-Fi Yes Ethernet LAN data rates 10,100,1000 Mbit/s Security algorithms 128-bit AES Supported network protocols IPv4, IPv6 Wi-Fi standards 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)

Aparat de fotografiat

Digital zoom 3 x Optical zoom 5 x Zoom capability Yes Horizontal field of view 82.1 ° Vertical field of view 52.2 ° Combined zoom 15 x Diagonal field of view 90 ° Remote control interface Bluetooth

afișaj

Display resolution 1280 x 800 pixels Display diagonal 10.1 " Touchscreen Yes Viewing angle, horizontal 85 ° Display brightness 400 cd/m² Contrast ratio (typical) 1000:1 Viewing angle, vertical 85 ° Oleophobic coating Yes Touchscreen type Capacitive Display IPS

Microfon

Microphone frequency 90 - 16000 Hz Microphone direction type Omnidirectional Microphone sensitivity -36 dB Number of microphones 6 Sound pressure level (max) 90 dB

Caracteristici

Cable lock slot Yes Cable lock slot type Kensington Telepresence No Motion sensor Yes

Computer system

Windows operating systems supported Windows 10,Windows 11 Mac operating systems supported Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey

Date logistice

Master (outer) case height 327 mm Master (outer) case length 1013 mm Master (outer) case width 270 mm Master (outer) case gross weight 12960 g

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 95 % Storage temperature (T-T) -40 - 70 °C Heat dissipation 64 BTU/h

Managementul energiei

Battery capacity 220 mAh Power source type AC AC input voltage 100 - 240 V Power plug type Type C DC input voltage 19 V Battery technology Lithium Current 4.74 A Number of batteries supported 2

Greutate şi dimensiuni

Height 164 mm Width 910 mm Depth 160 mm Weight 7080 g Package width 264 mm Package height 314 mm Package depth 1007 mm Package weight 12959 g Interface module dimensions (W x D x H) 246.2 x 171.3 x 56.1 mm Interface module weight 1000 g

Conţinutul de ambalaje

Quick start guide Yes AC adapter included Yes Remote control included Yes Mounting kit Yes Camera included Yes Power cable length 1.5 m HDMI cable length 2 m
