| General |
| Processor model | Intel Xeon W3-2425 |
| Operating system | Windows 11 Pro for Workstations |
| Software |
| Pre-installed software | 1 month trial version for new Microsoft® 365 user |
| Processor |
| Processor family | Xeon |
| Processor cores | Hexa-Core (6 Core) |
| Processor socket | FCLGA4677 Socket |
| Number of processors | 1 |
| Memory |
| Internal memory | 16 GB |
| Maximum internal memory | 2048 GB |
| Internal memory type | REG DDR5 ECC |
| Memory slots | 4 |
| Memory form factor | DIMM 240-PIN |
| Storage |
| Total storage capacity | 500 GB |
| HDD interface | 4x SATA 6Gb/s ports 1x M.2 slot (PCIe 4.0 x4/ available with 11th Gen CPU only) 1x M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) |
| RAID levels | RAID 0 RAID 1 RAID 5 RAID 10 RAID 1 RAID 5 RAID 10 |
| SSD interface | PCIe 4.0 |
| SSD capacity | 500 GB |
| HDD capacity | 1 x 500 GB - SSD |
| Storage media | SSD M.2 |
| Performance |
| Series | Workstation |
| Audio output channels | 8-channel |
| Motherboard chipset | Intel W790 |
| Design |
| Chassis type | Tower |
| Certification | ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar (Valid only for U.S.), EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
| Keyboard form factor | Optional |
| Keyboard |
| Keyboard language | International |
| Device interface | USB |
| Technical details |
| Localization | International |
| Field of use | Adobe Illustrator Autodesk 3ds Max |
| Expansion slots |
| Expansion slots | 1x PCIe 5.0/4.0/3.0 x16, 1x PCIe 4.0/3.0 x16 (supports x4 mode) 2x PCIe 3.0 x16 (supports x4 mode), 1x PCIe 3.0 x1 |
| Weight & dimensions |
| Height | 59.7 cm |
| Width | 25.4 cm |
| Depth | 59.8 cm |
| Weight | 21.5 kg |
| Other features |
| Interface | 1x USB 3.2 Gen USB Type-C, 1x USB 3.2 Gen 2 Type-A, 2x USB 3.2 Gen1, 2x USB 2.0, 1x DP 1.4, 1x HDMI 2.1, 1x Realtek 2.5Gb Ethernet RJ45, 5x Audio jacks, 1x Optical S/PDIF out port |
| Compatible operating systems | Windows 10 (64-Bit) Windows 11 (64-Bit) Unsupported OS by WAG: Linux (64-Bit) |
| Motherboard manufacturer | Asus Pro WS W790-ACE |
| Cooling type | Active |
| Compliance industry standards | CE, ISO 9001, Assembled in Germany Compatibility: PC2001, SMBios (DMI) 2.3, PCI 2.2,WFM 2.0, EnergyStar, EN60950, EN55022,EN55024, EN61000-3-2/3, 89/336/ECC |
| Special features | TPM 2.0 Secure Boot Windows Autopilot-ready |
| Mouse |
| Mouse included | TERRA wheel mouse optical |
| Graphics |
| On-board graphics adapter memory | 2 GB |
| Graphics card | NVIDIA RTX A2000 Professional Graphics (by PNY) |
| Graphics adapter ports | 4x DisplayPort |
| Power |
| Power source | ATX Netzteil 80 Plus Gold, 24-7 Dauerbetrieb geeignet Energy efficiency (Workload 20 %/ 50 % / 100 %): 87 %/ 90 % / 87 % |
| Maximum input power | 650 Watt |
| AC adapter input voltage | AC 100/240 V ( 50/60 Hz ) |
| Operational conditions |
| Operating temperature (T-T) | 10 °C - 32 °C |
| Maximum operating temperature range (T-T) | 32 °C |
| Recommended humidity operating range | 10 - 75% (non-condensing) |
| Network |
| Ethernet LAN | Netzwerkadapter - integriert |
| LAN controller | Realtek 2.5Gb Ethernet |
| Optical drive |
| Optical drive type | DVD±RW |
| Input device |
| Movement detection technology | Optical |
| Device interface | USB |
