Descriere
Performanță |
| Connectivity technology | Wired |
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Certification | CISPR 24, CISPR 35, EN 50121-4, EN 55024, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KC KN32 Class A, KC KN35, RCM AS/NZS CISPR32 Class A, VCCI Class A, IEC/EN/UL 60950-22, IEC/EN/UL 62368–1, IEC 60068-2-1, IEC/EN 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC/EN 60068-2-78, IEC/EN 60529 IP66/IP67, IEC/EN 62262 IK10b , ISO 21207 Method B, MIL-STD-810H (Method 501.7, 502.7, 505.7, 506.6, 507.6, 509.7, 510.7, 514.8, 516.8, 521.4), NEMA 250 Type 4X, NEMA TS 2 (2.2.7–2.2.9), NIST SP500-267 |
| Languages support | ENG,POL,ESP,ITA,POR,JPN,RUS,CHI (SIMPL),FRE,KOR,CHI (TR),DEU |
| Number of languages | 12 |
Design
Product colour Black,White Form factor Bullet Mounting type Ceiling/Wall International Protection (IP) code IP66, IP67 Housing material Aluminium,Polycarbonate (PC) IK code IK10
Aparat de fotografiat
Camera pixel size 17 µm Lens viewing angle, horizontal 19.4 °
Senzor de imagine
Sensor type Microbolometer Number of sensors 1 Effective sensor resolution (thermal module) 384 x 288 pixels
Sistem de lentile
Maximum aperture number 1.23 Fixed focal length 19 mm Number of lenses 1 Closest focusing distance 8.5 m Infrared spectral band 8 - 14 µm
Video
Maximum resolution 768 x 576 pixels Frame rate 30 fps Image quality adjustment Brightness,Contrast,Sharpness Video streaming Yes Privacy masking Yes Text caption overlay Yes Bit rate control Variable Bit Rate (VBR) Image stabilizer Yes Video formats supported H.264,H.265,AVC,MPEG4,HEVC,M-JPEG Flip & mirror Yes
Audio
Audio formats supported G.711,G.726,AAC-LC,LPCM,ADPCM,PCM Audio detection Yes Sample rate 8 kHz
Reţea
Ethernet LAN Yes Supported network protocols IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS , HTTP/2, SSL/TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, DHCPv4/v6, SOCKS, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf) Networking standards IEEE 802.3af,IEEE 802.3at Ethernet interface type Fast Ethernet,Gigabit Ethernet Quality of Service (QoS) support Yes Streaming method Multicast,Unicast
Medii de stocare
Compatible memory cards MicroSD (TransFlash),MicroSDHC,MicroSDXC Card reader integrated Yes Flash memory 512 MB ROM capacity 1024 MB
Conexiune
Ethernet LAN (RJ-45) ports 1 Microphone in Yes Terminal block port Yes
Securitate
IP address filtering Yes HTTPS encryption Yes Video motion detection Yes Password protection Yes Security algorithms EAP-TLS Alert notification type E-mail Active tampering alarm Yes Pixel counter Yes Digest authentication Yes
Managementul energiei
Power source type DC,PoE Power consumption (typical) 4.96 W Power consumption (max) 12.95 W DC output voltage 12,28
Conditii de mediu
Operating temperature (T-T) -40 - 60 °C Operating relative humidity (H-H) 10 - 100 % Storage temperature (T-T) -40 - 65 °C Storage relative humidity (H-H) 5 - 95 %
Greutate şi dimensiuni
Weight 1400 g Height 132 mm Width 132 mm Depth 272 mm
Conţinutul de ambalaje
Number of cameras 1 Manual Yes Mounting brackets included Yes
Detalii tehnice
Doesn''t contain PVC,BFR,Halogen
Date logistice
Harmonized System (HS) code 85258900
