Conexiune
DC-in jack	Yes
Keyboard port type	USB
Mouse port type	USB
Video port type	HDMI
Number of computers controlled	1
Audio connections	Yes
Headphone outputs	3
Console USB ports quantity	4
Console ports	3.5mm headphone,HDMI,USB A
HDMI ports quantity	3
HDMI version	2.0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity	2
USB hub	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity	2

Performanță

Maximum resolution 3840 x 2160 pixels Chipset Genesys Logic - GL3523 HDCP Yes HD type 4K Ultra HD Number of users 1 user(s) Daisy chain No Audio channels 7.1 Data transfer rate (max) 5 Gbit/s

Design

Product colour Black Rack mounting Yes Housing material Steel Certification CE, RoHS, FCC LED indicators Yes Mean time between failures (MTBF) 143000 h Push button Yes Hot keys Yes

afișaj

Built-in display No On Screen Display (OSD) No

Managementul energiei

AC input voltage 100 - 240 V Input current 1 A Power consumption (typical) 36 W Compatible power plug types EU,JP,UK,US Output current 3 A Output voltage 12 V External power adapter Yes Power plug type Type M

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -10 - 60 °C Operating relative humidity (H-H) 0 - 80 %

Greutate şi dimensiuni

Weight 640 g Width 100 mm Depth 160 mm Height 40 mm

Datele de ambalare

Package weight 147 g Package width 238 mm Package depth 180 mm Package height 91 mm

Conţinutul de ambalaje

AC adapter included Yes

Date logistice

Master (outer) case width 397 mm Products per master (outer) case 6 pc(s) Master (outer) case height 305 mm Master (outer) case length 265 mm Harmonized System (HS) code 85176200

Alte caracteristici

IP control No
